I have not tested this item.

I've a question:
To see the JSON I just need to add api / index.php / v1 / content / article to the article URL?

I'm not very familiar with APIs!

@alikon this should be the Fully Qualified Domain name to the image not just the path

Go to the Home Dashboard:

Notice: Undefined property: stdClass::$images in \administrator\components\com_content\src\Model\ArticlesModel.php on line 655

@wilsonge can you re-check it now
@Quy no more Notice

I don't know enough to test this. My article URL is http://localhost/j4bugtest/index.php/en/blog/3-welcome-to-your-blog

Editing to .../api/index.php/v1/content/... in any combination I have tried just gives me a Not Found response. So what should the api url look like?

@adj9 @ceford To test the API you need to connect to it somehow. You can use Joomla's HTTP library, cURL or an external application like Postman.

@adj9 . @ceford

an easy way to test if you don't want to use tools like Postman

1. disable API Authentication - Joomla Token plugin
2. enable API Authentication - Basic Auth plugin
3. create a super user: admin psw: admin
4. put this script on your root folder site
5. change CURLOPT_URL accordingly
6. run this script from terminal or from browser

<?php

$curl = curl_init();

curl_setopt_array($curl, array(
  CURLOPT_URL => "http://localhost/quattro/api/index.php/v1/content/article",
  CURLOPT_RETURNTRANSFER => true,
  CURLOPT_ENCODING => "",
  CURLOPT_MAXREDIRS => 10,
  CURLOPT_TIMEOUT => 0,
  CURLOPT_FOLLOWLOCATION => true,
  CURLOPT_HTTP_VERSION => CURL_HTTP_VERSION_1_1,
  CURLOPT_CUSTOMREQUEST => "GET",
  CURLOPT_HTTPHEADER => array(
    "Accept: application/vnd.api+json",
    "Authorization: Basic YWRtaW46YWRtaW4="
  ),
));

$response = curl_exec($curl);

curl_close($curl);
echo $response;

It is not returning as object.

"images": "{\"image_intro\":\"images\\/joomla_black.png\",\"float_intro\":\"\",\"image_intro_alt\":\"a\",\"image_intro_caption\":\"b\",\"image_fulltext\":\"images\\/powered_by.png\",\"float_fulltext\":\"\",\"image_fulltext_alt\":\"c\",\"image_fulltext_caption\":\"d\"}",

@Quy are you talking about the example script ?

I expect it to look like your screenshot, but this instead:

this is what I got in postman .... so unable to reproduce your findings

with single article without an images or with a list of articles....

Installed the package from here: https://ci.joomla.org/artifacts/joomla/joomla-cms/4.0-dev/29020/downloads/32042/

Assigned images:

{
    "errors": {
        "code": 500,
        "title": "Internal server error"
    }
}

Removed images:

                "images": {
                    "image_intro": "",
                    "float_intro": "",
                    "image_intro_alt": "",
                    "image_intro_caption": "",
                    "image_fulltext": "",
                    "float_fulltext": "",
                    "image_fulltext_alt": "",
                    "image_fulltext_caption": ""
                },

Still baffled! Without the patch the api script using curl given above recovers all 15 articles (valid json) in descending order with no mention of images. With the patch I get the Internal server error message.

i've appliyed this pr with com_patchtester on the latest 4.0-dev iand unable to replicate your 500
@Quy may I ask you to test it with com_patchtester ?

I have tested this item ✅ successfully on 235d9f8

A couple of things I have discovered:

Adding this line to the curl script given above allows debugging (I am using Eclipse):
CURLOPT_COOKIE => 'XDEBUG_SESSION=1',

With the patch applied using com_patchtester:

On stepping through the code I get to administrator/components/com_content/src/Helper/contentHelper.php line 232:
$uri = Psr7\uri_for($uri);
and that statement throws a fatal error.
This morning I updated my bugtest installation on-line from the nightly build.

Is this helpful?

I have tested this item ✅ successfully on 235d9f8

Tested with nightly build and Path Tester and fail --> We think is a problem with the package of the nightly

Downloaded source from github, compiled and tested: Works correctly.
Tested with intro and fulltext images, float, alt, caption.
Also tested with external url image.

Also tested POST.

PERFECT!

{
    "links": {
        "self": "https://j4.jugmi.it/api/index.php/v1/content/article"
    },
    "data": {
        "type": "articles",
        "id": "6",
        "attributes": {
            "typeAlias": "com_content.article",
            "id": 6,
            "asset_id": 92,
            "title": "Test Api Nicola 5",
            "state": 0,
            "created": "2020-05-16 08:00:19",
            "images": {
                "image_intro": "https://leganerd.com/wp-content/uploads/2020/03/google-classroom-cover-999x500.jpg",
                "float_intro": "none",
                "image_intro_alt": "Intro alt",
                "image_intro_caption": "Intro capt",
                "image_fulltext": "https://www.fastweb.it/var/storage_feeds/CMS/articoli/108/10840b1e803a03d644e95dd60efa9f64/480x270.jpg",
                "float_fulltext": "left",
                "image_fulltext_alt": "Full alt",
                "image_fulltext_caption": "Full capt"
            },
            "language": "*",
            "tags": [],
            "text": "Test Pubblicazione Articolo con Nicola 5 "
        },
        "relationships": {
            "category": {
                "data": {
                    "type": "categories",
                    "id": "2"
                }
            },
            "author": {
                "data": {
                    "type": "users",
                    "id": "385"
                }
            }
        }
    }
}

@alikon can you enable to add a custom path before clicking on the select icon, that saves admins a LOT of time...

@coolcat-creations this pr is about the api application and not the administrator application

@ceford sure it helped us to discover the root of the issue, i've used that library "Guzzle"which is present on dev but it is not delivered on the nightly build... let's see if that library it is necesssary or not to be delivered on the final "nighly" package.... work in progress...

You should be able to use the HttpFactory instead of Guzzle.

Just prefix the value with Joomla\CMS\Uri\Uri::root() - there's no need for any of the helper work as far as I can tell?

well that will work with "internal" path like images/sampledata/fruitshop/apple.jpg

not for external one like
https://www.fastweb.it/var/storage_feeds/CMS/articoli/108/10840b1e803a03d644e95dd60efa9f64/480x270.jpg

? what i'm missing ?

not for external one like
https://www.fastweb.it/var/storage_feeds/CMS/articoli/108/10840b1e803a03d644e95dd60efa9f64/480x270.jpg

Can you please explain how do you get that external file to that place in the first place? And when you have successfully added it why is that a problem now?

You might only prefix the images with Joomla\CMS\Uri\Uri::root() when they are not starting with "http" already?

if you use the API POST for create an article you can set "image_intro" with an external url

curl -X POST -H "Content-Type: application/json" /api/index.php/v1/content/article -d

{
    "alias": "my-article",
    "articletext": "My text",
    "catid": 64,
    "language": "*",
    "metadesc": "",
    "metakey": "",
    "images": {
                "image_intro": "https://leganerd.com/wp-content/uploads/2020/03/google-classroom-cover-999x500.jpg",
                "float_intro": "none",
                "image_intro_alt": "Intro alt",
                "image_intro_caption": "Intro capt",
                "image_fulltext": "https://www.fastweb.it/var/storage_feeds/CMS/articoli/108/10840b1e803a03d644e95dd60efa9f64/480x270.jpg",
                "float_fulltext": "left",
                "image_fulltext_alt": "Full alt",
                "image_fulltext_caption": "Full capt"
            },
    "title": "Here's an article"
}

with the backend you cannot see #28852

Ok so when the url is set to an external already you don't have to touch it right? So the only case you would need to touch it is when it is just a relative URL?

Idea than would be to check whether is starts with www and if no add uri::root and in the other case dont touch it.

Would that work?

removed Guzzle
ready to be re-tested

I have tested this item ✅ successfully on 32e7210

Tested successfully in Nightly Build of 24 May.

@alikon @wilsonge - if 'Use URL Rewriting' is selected in Global Configuration - SEO, the API reports a 404 error. Is this a known issue or should I report it? My test environment is Wampserver 3.2.1 with Apache 2.4.41 MySQL 8.0.19 PHP 7.4.5

Error: {"errors":[{"title":"Resource not found","code":404}]}

@toivo see if #28394 solves your issue.

@SharkyKZ - Yes and no - after #28394 was applied when 'Use URL Rewriting' was selected, the API worked all right. However, if 'Use URL Rewriting' was NOT selected, the API produced the error 404 - Resource not found. The API should work in both cases, IMHO.

@toivo Yes API should work in either case. However I think #29303 should have fixed this.

PHP Warning: Invalid argument supplied for foreach() in \administrator\components\com_content\src\Model\ArticlesModel.php on line 649

PHP Warning: Invalid argument supplied for foreach() in \libraries\src\MVC\View\JsonApiView.php on line 126

good catch, this pr was made before workflow v3 was merged so the administrator/components/com_content/src/Model/ArticlesModel.php included in this pr was old

now should be ok

I have tested this item ✅ successfully on af796ce

@bembelimen can you test this please? The admin model changes required here from workflows especially

Looks like upstream changes were applied manually to one file.

@alikon Can you revert last commit and merge upstream branch instead?

redone #29630
